Horizontal Electric Heating Rubber Roller Vulcanizing Tank, Small Vulcanizing Equipment & Stainless Steel Vulcanizing Autoclave
$0.00
Description
Custom Processing Available: Yes
Effective Inner Volume: 8 m³
Width: 1500 mm
Style: Horizontal Vulcanizing Autoclave
Effective Length: 6000 mm
Operation Mode: Electric Heating
Diameter: 1500 mm
Weight: 2000 kg
Working Pressure: 0.58 MPa
Product Type: Vulcanizing Autoclave
Working Temperature: 150℃
Main Motor Power: 5.5 kW
Overall Dimension: 1.5 m × 6 m
Vulcanizing autoclaves are generally equipped with an intelligent automatic control system. Temperature sensors collect real-time temperature data inside the tank and transmit the data to the control cabinet for display and processing. The control system automatically adjusts heating and heat preservation modes according to preset temperature ranges to guarantee accurate and stable internal tank temperature. It will automatically open the heating valve when the temperature falls below the set value and close the heating valve once the target temperature is reached, achieving energy-saving and high-efficiency heat retention.
Sealing Structure
Double-layer External Thermal Insulation
Features
- It relies on an external steam source such as a boiler and requires a matched steam supply system.
- Fast temperature rise; the humid-hot atmosphere enables uniform vulcanization of rubber products.
- High heat capacity of steam makes it suitable for continuous and large-scale production.
- Low operating cost. The unit can also generate steam by heating water with built-in bottom electric heating tubes.
- Condensate drainage treatment is required; regular maintenance of steam pipelines and valves is necessary to prevent corrosion.
High Production Efficiency
The vulcanizing autoclave completes vulcanization of rubber products within a short period to boost production efficiency and meet the demands of mass production. In addition, its high level of automation cuts manual operation time and labor intensity, further lifting overall production efficiency.
Uniform Heating
Vulcanizing autoclaves with various heating modes can deliver excellent temperature uniformity. Equipped with an integrated high-temperature and high-pressure fan, the equipment drives medium-speed circulation of hot air inside the tank through air duct plates to evenly distribute heat, ensuring uniform temperature throughout the chamber without dead zones.
Excellent Sealing Performance
This equipment adopts inflatable sealing rings to achieve superior tightness. Once pressure builds up inside the tank, the sealing ring expands outward and presses firmly against the tank door to form a reliable seal, maintaining stable internal pressure. Higher pressure results in better sealing performance. Meanwhile, the sealing ring features a long service life with simple and convenient maintenance.
